DNGA PCBN brazing inserts user vacuum welding solid CBN tip, with high welding strength, high wear resistance, can withstand large cutting force suitable for machining conditions ＜3mm cutting depth.Due to the use of integrated welding technology, both sides of the teeth can be processed, increase the cutting edge, improve the utilization of the DNGA PCBN inserts.
| TYPE | SIZE | ||||
| ISO | L | φi.c | s | φd | r |
| DNGA110404-4S | 11 | 9.525 | 4.76 | 3.81 | 0.4 |
| DNGA110408-4S | 11 | 9.525 | 4.76 | 3.81 | 0.8 |
| DNGA110412-4S | 11 | 9.525 | 4.76 | 3.81 | 1.2 |
| DNGA150404-4S | 15 | 12.7 | 4.76 | 5.16 | 0.4 |
| DNGA150408-4S | 15 | 12.7 | 4.76 | 5.16 | 0.8 |
| DNGA150412-4S | 15 | 12.7 | 4.76 | 5.16 | 1.2 |
| The standard edge of DNGA pcbn inserts is T01020, T01020, S01020, S02020 | |||||
